1
WWW.FOXCH.COM
SAFE
STRONG
ALL PROOF
FOX AXLES
2
CHICHEST AXLE MANUFACTURING CO.
3
ww
w.foxch.com
Indipendent forces
working peferctly together.
WWW.FOXCH.COM
CONTENT
INTRODUCTION
6-23
01.AXLES
24-33
02.AXLE SPARE PARTS
34-51
03.SEMI TRAILERS PARTS
52-73
04.CURTAIN SIDER PARTS
74-80
GUIDE
CHICHEST AXLE MANUFACTURING Co.
W W W . F O X C H . C O M
Stainless Steel
G Hot Galvanized
Powder Painting
S
HOT
Address: 10Km of Mahabad Rd., Urmia - Iran
Tel: +98 (44) 33 38 18 41
Fax: +98 (44) 33 38 18 57
Aluminum
G
Cold Galvanized
Liquid Painting
COLD
Al
Postal Code: 57311 - 69587
Instagram: fox.msc
X
No Coating
D Docrotized
Chromized
Color by order
CHICHEST AXLE MANUFACTURING CO. (FOX)
PRODUCTS GENERAL CATALOGE (ENGLISH)
V.1.9.4
(WINTER 2019)
4
CHICHEST AXLE MANUFACTURING CO.
5
INTRODUCTION
WWW.FOXCH.COM
mercial vehicle axle in middle East. It’s
Relying on our engineering group
ROADS ARE NOW
located at the north west of iran that
and using most advanced technology
has border with three country at the
and establishing quality managment
CONQUERED BY
same time. Total area of 100,000 m2
system such as ISO 9001:2008 we
and about 50,000 m2 production area
are believed in our products quality.
OUR AXLES
that utilized with the most developed
Complete set of advanced equip-
machinery was built to serve an an-
ment and through inspection/testing
Mehvar sazan chichest co. business
nual output capacity of 15,000 pieces
system are well operated to generate
brand FOX ,is the first leading man-
of axles with weight rating of 9 to 20
the standard products conforming to
ufacturer of semi-trailer and com-
tons per year.
customer requirements.
6
CHICHEST AXLE MANUFACTURING CO.
7
ENGINEERING DEPARTMENT
WWW.FOXCH.COM
Engineering
Department
Relying on technical Knowledge and
experiences of the mechanical engineers,
designing , engineering and manufactur-
ing various kind of metal dies ( punching
, bending , deep drawing and etc. ) , cast-
ing models, plastic injection molds and
die casting molds and welding fixtures
have been doing by using the latest CAD,
CAM, CAE, ED software such as CATIA,
Power Mill and Auto Form.
8
CHICHEST AXLE MANUFACTURING CO.
9
AXLE PRODUCTION LINE
WWW.FOXCH.COM
innovation
&ingeunity
FOX AXLEPRODUCTION
LINE
10
CHICHEST AXLE MANUFACTURING CO.
11
AXLE PRODUCTION LINE
WWW.FOXCH.COM
As the main production unit of the company, this unit,
Axle Production Line
is capable of producing and assembling different kinds
of commercial vehicles axles, according to latest version
of European standards by using precision instruments
and special fixtures. The Axles deliver to customers
after doing ABS and EBS test and other road tests.
12
CHICHEST AXLE MANUFACTURING CO.
13
MACHINING WORKSHOP
WWW.FOXCH.COM
Machining
Workshop
This section is equipped with the latest and most advanced machine tools such as CNC milling and Turning and EDM Wire
Cut machine. In this unit all kind of machining processes have been done to manufacture molds and dies by using knowl-
edge and experience of human resources.
14
CHICHEST AXLE MANUFACTURING CO.
15
PRESSING WORKSHOP
WWW.FOXCH.COM
Pressing
Workshop
In this section different industrial sheet metal parts being produced by 45 to
400 tons hydraulic and eccentric presses and using the capabilities of skilled
manpower for supplying other units. In this unit, various operation such as
trimming, punching, bending and deep drawing is done on different parts with
the capacity of 1,000,000 parts per month.
16
CHICHEST AXLE MANUFACTURING CO.
17
AIR TANK PRODUCTION LINE
WWW.FOXCH.COM
Air Tank Production Line
In this line, wide variety of Air Tanks and oil tanks used
in commercial vehicles with different sizes and volumes
are being produced using automatic welding fixtures
according to ISO 17636-1 and CE standards.
18
CHICHEST AXLE MANUFACTURING CO.
19
PAINTING LINE
WWW.FOXCH.COM
Before painting the parts, are
Painting
degreased and by substances such as
phosphates, surface perpetration for
Line
painting done and then completely
dried by hot air flow.
The company is equipped with two
Then, the parts are carried by con-
liquid and powder painting line which
tinuous conveyer to painting cabins,
is designed and built with the latest
then Transfer to the furnace until they
world technology and including the
are cooked at temperature of about
following units:
200 ° C. this kind of painting has very
- washing
high resistant to physical impact and
- degreasing
chemical corrosion and also accord-
- drying
ing to HSE, powder painting is more
- painting cabin
safe for environment.
- painting robots
- Furnace
20
CHICHEST AXLE MANUFACTURING CO.
21
WAREHOUSE
WWW.FOXCH.COM
Warehouse
According to latest methods of ware-
housing all goods have been sorted
by using the BOM and methods such
as FIFO, FILO, LIFO, LILO to assure safe
stocking and handling with minimum
storage time and availability.
22
CHICHEST AXLE MANUFACTURING CO.
23
01. AXLES / AIR DISC BRAKE AXLES - DRUM BRAKE AXLES
WWW.FOXCH.COM
01
AXLES
Air disc brake
Drum brake
24
CHICHEST AXLE MANUFACTURING CO.
25
WWW.FOXCH.COM
RIDE THE ROADS WITH
EASE & COMFORT
Fox axles advantages and superior specifications:
- Due to ruling conditions on middle-east roads and
climate specifically Iran, several problems such as parts
or whole axle body fracture and decreasing life and
depreciation of axles and heavy maintenance costs all
include truck drivers and logistic and transportation
companies which used to utilize semi trailers with
European brands.
Checking all analysis reports and several experiments
and observations, Mehvar-sazan chi-chest engineer-
ing group succeeded to design and manufacture
semi-trailer axles which performed amazingly through
a improvements and reforms to make it least of all
current problems and difficulties.
Consider changes such as:
- Replacing NO.24 bolt screw heals for hanger bracket
by no.30 in 9 tons axles
- Using standard roll bearings (two pieces) which
resulted in falling down all maintain and repair costs
more then 85%
- Using special formulated grease that is dou-
ble-time resistance against high temperature (400°cg)
comparing with other European brands
- Usage of bigger calipers being used with most famous
world axle manufacturers which increase power of
brakes and reasonable maintaining process, all leading
to 80% decrease in repairing and maintaining costs
- Authoritative guarantee, extensive and capillary after
sales services based on customer satisfactions and
upgraded staff and machineries and spare parts supply
warranty with maximum quality and most reasonable
and affordable prices and costs has all caused drivers
first choice to be fox semi-trailers axles and make them
set to ride the roads with ease and comfort.
26
CHICHEST AXLE MANUFACTURING CO.
27
01. AXLES / AIR DISC BRAKE AXLES - DRUM BRAKE AXLES
WWW.FOXCH.COM
3x9 Air Disc Brake Axle
3x9 Intra Air Disc Brake Axle
With Leaf Trailing Arm (7cm)
With round axle
SPECIFICATION
SPECIFICATION
Permitted axle load
9000 kg
Tyres
Single
Permitted axle load
9000 kg
Tyres
Single
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Spring Center
1300
Track Width
2010 mm
Spring Center
1300
Track Width
2010
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
70 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
-
Brake
Disc
Caliper
KNORR-BREMSE
Brake
Disck
Caliper
KNORR
Bearing
SKF-33213/33118
Exciter ring
ok
Bearing
SKF-33213/33118
Exciter ring
ok
Axle Cross Section
120x120x14
Air Bag
8940 kpp
Axle Cross Section
Ø148x14
Air Bag
2619 V
Axle Weight
Axle Weight
Axle Weight
497.5 kg
522 kg
Axle Weight
473 kg
490 kg
(with lift set)
(with lift set)
3x9 Air Disc Brake Axle
3x9 Intra Drum Brake Axle
With Leaf Trailing Arm (10cm)
With round axle
SPECIFICATION
SPECIFICATION
Permitted axle load
9000 kg
Tyres
Single
Permitted axle load
9000 kg
Tyres
Single
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Spring Center
1300
Track Width
2010 mm
Spring Center
1300 mm
Track Width
2040 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
100 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
-
Brake
Disc
Caliper
KNORR-BREMSE
Brake
Drum- 420x200
Air Cylinder Center
393 mm
Bearing
SKF-33213/33118
Exciter ring
ok
Bearing
SKF-33213/33118
Exciter ring
ok
Axle Cross Section
120x120x14
Air Bag
8940 kpp
Axle Cross Section
Ø148x14 mm
Air Bag
2619 V
Axle Weight
Axle Weight
497.5 kg
522 kg
(with lift set)
28
CHICHEST AXLE MANUFACTURING CO.
29
01. AXLES / AIR DISC BRAKE AXLES - DRUM BRAKE AXLES
WWW.FOXCH.COM
2x12 Drum Brake Axle
2x12 Drum Brake Axle (For lowbed)
With Leaf Trailing Arm (10cm) - With square axle
With Leaf Trailing Arm (10cm) - With round axle
SPECIFICATION
SPECIFICATION
Permitted axle load
12000 kg
Tyres
Twin
Permitted axle load
12000 kg
Tyres
Twin
Tyre Example
315/80 R22.5
Paint System
Epoxy electro static
Tyre Example
245/65 R17.5
Paint System
Epoxy electro static
Spring Center
900 mm
Track Width
1840 mm
Spring Center
1050 mm
Track Width
1931 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
100 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
100 mm
Brake
Drum- 420x200
Air Cylinder Center
301 mm
Brake
Drum- 360x259
Air Cylinder Center
490 mm
Bearing
SKF-33213/33118
Exciter ring
ok
Bearing
SKF-33213/33118
Exciter ring
ok
Axle Cross Section
150x150x12
Air Bag
8813
Axle Cross Section
Ø127x93x1650
Air Bag
8881
3x9 Drum Brake Axle
Bogie Drum Brake Axle
With Leaf Trailing Arm (7cm)
SPECIFICATION
SPECIFICATION
Permitted axle load
9000 kg
Tyres
Single
Permitted axle load
40000 kg
Tyres
Twin
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Tyre Example
12.00 - 20
Paint System
Epoxy electro static
Spring Center
1300 mm
Track Width
2045 mm
Spring Center
980 mm
Track Width
1920 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
70 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
-
Brake
Drum- 420x200
Air Cylinder Center
380 mm
Brake
Drum- 420x200
Air Cylinder Center
-
Bearing
SKF-33213/33118
Exciter ring
ok
Bearing
32314 / 32222
Exciter ring
-
Axle Cross Section
120x120x14 mm
Air Bag
Aktash 8813
Axle Cross Section
150x150x16 mm
Air Bag
-
30
CHICHEST AXLE MANUFACTURING CO.
31
01. AXLES / AIR DISC BRAKE AXLES - DRUM BRAKE AXLES
01. AXLES / AIR DISC BRAKE AXLES - DRUM BRAKE AXLES
2x12 Drum Brake Axle
3x9 Drum Brake Axle
With Leaf Trailing Arm (10cm) - With round axle
With Leaf Trailing Arm (7cm) - With round axle
SPECIFICATION
SPECIFICATION
Permitted axle load
9000 kg
Tyres
Single
Permitted axle load
12000 kg
Tyres
Twin
Tyre Example
385/65 R22.5
Paint System
Epoxy electro static
Tyre Example
315/80 R22.5
Paint System
Epoxy electro static
Spring Center
1300 mm
Track Width
2045 mm
Spring Center
900 mm
Track Width
1850 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
70 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
100 mm
Brake
Drum- 420x200
Air Cylinder Center
380 mm
Brake
Drum- 420x200
Air Cylinder Center
381 mm
Bearing
SKF-33213/33118
Exciter ring
ok
Bearing
SKF-33213/33118
Exciter ring
ok
Axle Cross Section
Ø120x120x14 mm
Air Bag
Aktash 8813
Axle Cross Section
Ø148x14 mm
Air Bag
2918 V
2x12 Intra Drum Brake Axle
With round axle
SPECIFICATION
Permitted axle load
12000 kg
Tyres
Twin
Tyre Example
315/80 R22.5
Paint System
Epoxy electro static
Spring Center
900 mm
Track Width
1850 mm
Wheel Stud
10 - M 22x1.5
Leaf trailing arm
-
Brake
Drum- 420x200
Air Cylinder Center
401 mm
Bearing
SKF-33213/33118
Exciter ring
ok
Axle Cross Section
Ø148x14 mm
Air Bag
2918 V
32
CHICHEST AXLE MANUFACTURING CO.
33
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
02
AXLE SPARE PARTS
Air Disc Brake Axle Hub
Axle Hub Cap
Axle Roller Bearing
ABS Ring
Hanger Bracket
& ...
34
CHICHEST AXLE MANUFACTURING CO.
35
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX Air Disc Brake Axle Hub Assembly
Code
Name
01.201.201
FOX 3x9 Air Disc Brake Axle Hub
01.201.202
FOX Brake Disc
01.201.203
FOX Roller Bearing (Small)
01.201.204
FOX Roller Bearing (Large)
01.201.206
FOX Metal Duster
01.201.207
FOX Locking Rings
01.201.208
FOX Locking Rings
01.201.209
FOX Cartridge
01.201.210
FOX Seal
01.201.211
FOX Plastic Seal
01.201.212
FOX ABS Ring
01.201.213
FOX Bolt (Wheel Stud)
01.201.214
FOX Nut (Wheel Stud)
01.201.215
FOX Axle Thrust Washer
01.201.216
FOX Axle Lock Nut
01.201.217.01
FOX Axle Speil Pin
01.201.217.02
FOX Axle Speil
01.201.219
FOX Axle Hub Cap
36
CHICHEST AXLE MANUFACTURING CO.
37
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX Drum Brake Axle Hub Assembly
Code
Name
03.201.203
FOX 3x9 Air Disc Brake Axle Hub
03.201.202
FOX Brake Drum
01.201.203
FOX Roller Bearing (Small)
01.201.204
FOX Roller Bearing (Large)
01.201.206
FOX Metal Duster
01.201.207
FOX Locking Rings
01.201.208
FOX Locking Rings
01.201.209
FOX Cartridge
01.201.210
FOX Seal
01.201.211
FOX Plastic Seal
01.201.212
FOX ABS Ring
01.201.213
FOX Bolts (Wheel Stud)
01.201.214
FOX Nuts (Wheel Stud)
01.201.215
FOX Thrust Washer
01.201.216
FOX Axle Lock Nut
01.201.217
FOX Axle Speil
01.201.219
FOX Axle Hub Cap
38
CHICHEST AXLE MANUFACTURING CO.
39
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX 3x9 Air Disc Brake Axle Hub
FOX Axle Lock Nut With Thrust Washer
01.201.201
01.201.215 / 01.201.216 / 01.201.217
X
FOX 3x9 Drum Brake Axle Hub
FOX Pole Wheel
03.201.203
01.201.212
G
COLD
FOX Axle Hub Cap
FOX Locking Rings
01.201.219 / 04.201.219
01.201.207 / 01.201.208
X
40
CHICHEST AXLE MANUFACTURING CO.
41
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX Brake Disc
FOX Drum Brake Shoes with Pad
01.201.202
02.101.116
X
FOX Brake Drum
FOX Automatic and Manuel Slack Adjuster
03.201.202
02.301.307
FOX Shoes Springs
FOX Brake S-Cam with Fasteners
03.301.000
Hook Spring Type 1: 02.301.331 / Hook Spring Type 2: 02.301.332 / Connector Spring: 02.301.330
G
COLD
42
CHICHEST AXLE MANUFACTURING CO.
43
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX Shock Absorber
FOX Leaf Spring (7 cm)
01.401.407
01.401.401
FOX Axle Air Bags
FOX Leaf Spring (10 cm)
01.401.405
01.402.401
FOX U-Bolts
FOX Leaf Spring (7 cm / Deep)
01.403.401
Axle Type
Code
A
B
C
3x9 Disc Brake Axle
01.401.408
150
320
M24x3
2x12 Drum Brake Axle
05.401.404
152
318
M24x3
44
CHICHEST AXLE MANUFACTURING CO.
45
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX Bolts and Nuts
FOX Brake Chamber
T 16 / 24
Dimension
Length
Axle Type
Description
Code
(mm)
(mm)
Wheel Stud
M22x1.5
80
01.201.213
Hanger Bracket Bolt
M30x3.5
175
01.301.320
3x9 Disc
Brake Axle
Lift Set Bolt
M30x3.5
235
01.301.305
Shack Absorber Bolt
M24x3
240
01.301.307
Wheel Stud
M22x1.5
90
02.201.213
3x9 &
Hanger Bracket Bolt
M30x3.5
210
02.301.320
2x12
Drum
Lift Set Bolt
M30x3.5
270
02.301.305
Brake Axle
Shack Absorber Bolt
M24x3
275
02.301.307
D
FOX Brake Chamber
FOX Brake Chamber
T 30/30
T 16
FOX Brake Chamber
FOX Axle Lifting Chamber
T 30
T 36
46
CHICHEST AXLE MANUFACTURING CO.
47
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
WWW.FOXCH.COM
FOX 100 mm Axle Lifting Set
FOX Hanger Bracket
01.303.000
01.301.301
X
FOX 70 mm Axle Lifting Set
FOX Hanger Bracket (7 cm - Long)
01.301.000
24 Bushing: 01.302.302 / 30 Bushing: 01.302.301
X
FOX Intra Axle lifting Set (Type 2)
FOX Hanger Bracket (7 cm - Short)
V1025
24 Bushing: 01.301.302 / 30 Bushing: 01.301.301
X
48
CHICHEST AXLE MANUFACTURING CO.
49
02. AXLE SPARE PARTS / AIR DISC BRAKE AXLE HUB - AXLE HUB CAP - AXLE ROLLER BEARING - ABS RING - HANGER BRACKET & ...
FOX Intra Hanger Bracket (Type 2 - Long)
04.304.301
X
FOX Intra Hanger Bracket (Type 2 - Short)
04.303.301
X
50
CHICHEST AXLE MANUFACTURING CO.
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
03
SEMI TRAILERS PARTS
Air Tank
Mud Guard & Clamp
Water Tank
Hydraulic Cylinder
Tool Boxes
52
CHICHEST AXLE MANUFACTURING CO.
53
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Air Tank
FOX Air Tank Saddle
Air tanks are equipments used for commercial vehicles or the trailers.
they store and when needed, provide the pneumatic brake systems or the interior auxiliary equipments of them.
TECHNICAL INFORMATION:
Specification
87/404/E.E.C
Norm
EN 286-2/1992
Testing pressure
1.5 times of working pressure
Connection to Air
Th
Part Name
Available for
Coating
Tank
(mm)
Working Pressure
10.5 - 12.5 - 15.5 bar
AT.396.60.01
Temp. Range
T min = -50°C , T max = +100°C
Saddle SP
Using Clamping Belt
2
AT.396.80.01
Galvanized
External paint
Epoxy powder coating (black)
1001.01
AT.396.100.01
G
COLD
FOX Air Tank Saddle
Capacity (Lit)
Diameter
Length
Number of Ports
Working Pressure
Weight
Product Number
+ 4%
(D) (mm)
(L) (mm)
(M 22x1.5)
(bar)
(kg)
AT.154.05.01
5
154
345
3
15.5
3.2
AT.206.10.01
10
206
370
4
15.5
4.8
AT.206.15.01
15
206
530
4
15.5
6.5
AT.206.20.01
20
206
690
4
15.5
8.1
Connection
Th
Part Name
Available for
Coating
to Air Tank
(mm)
AT.206.20.01
20
246
500
4
15.5
7.5
AT.276.30,40,60.01
AT.246.25.01
25
246
610
4
15.5
8.9
Bracket
Epoxy powder
Welded
2
AT.246.20,25,30,40.01
AT.246.30.01
30
246
720
4
15.5
10.2
Type 1
coating (Black)
AT.206.10,15,20.01
AT.246.40.01
40
246
940
4
15.5
13.3
AT.276.30.01
30
276
585
4
12.5
10.7
G
AT.276.40.01
40
276
760
4
12.5
12.6
COLD
AT.276.60.01
60
276
1110
4
12.5
16.5
AT.310.40.01
40
310
620
4
10.5-12.5
11
AT.310.60.01
60
310
895
4
10.5-12.5
15.7
FOX Air Tank Saddle
AT.310.80.01
80
310
1162
4
10.5-12.5
19.4
AT.396.60.01
60
396
580
4
10.5-12.5
16.5
AT.396.80.01
80
396
750
4
10.5-12.5
22
AT.396.100.01
100
396
915
4
10.5-12.5
25.2
Air Tank
R
L
H
W
A
S
T
E
Thickness
Code
AT.276
138
200
54
34
140
10
20
13
4 mm
SP1001.03
AT.246
123
200
54
34
140
10
20
13
4 mm
SP1001.04
AT.206
103
160
54
34
120
10
20
13
4 mm
SP1001.05
54
CHICHEST AXLE MANUFACTURING CO.
55
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX 3 Set Axle Mud Guard
FOX Mud Guard Clamp 2 Axle (Type 1)
MG.01.01
MGC.03
Material : PP
G
COLD
FOX Mud Guard
FOX Mud Guard Clamp 3 Axle (Type 1)
MG.01.02
MGC.01
Material : PP
G
COLD
FOX Mud Flap
FOX Mud Guard Clamp 3 Axle (Type 2)
MF.01.01
MGC.02
Material : PVC
G
COLD
56
CHICHEST AXLE MANUFACTURING CO.
57
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Mud Guard Holder
FOX Rear Damper
Long: MG.01 / Medium: MG.02 / Single Bolt: MG.03
RD.01
G
G
HOT
D
HOT
FOX Water Tank (30 litters)
FOX Rear Damper
WT.01.00
RD.02
S
D
GHOT
FOX Side Profile Holder
FOX Rear Damper
APH.01.01
RD.03
G
G
COLD
D
HOT
58
CHICHEST AXLE MANUFACTURING CO.
59
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Hydraulic Cylinder
FOX Off-Roud Bracket (Type 1)
TTS.01
Maximum
Working
Maximum
Code
Type
Stroke
Working
Oil Capacity
Pressure
Pomp Flow
Pressure
TF
100.03.290
5384 mm
190 bar
107 L
271 bar
140 L/min
192/5/5384
Dimensions *
Ext
A
1441
73
B
248
92
111
C
65
130
D
60
150
E
52
170
F
SAE 1”
192
G
74
215
H
1497
FOX On-Roud Bracket (Type 2)
I
50,8
TTS.02
J
215
K
400
L
222
M
140
N
120
LC = 7500 [mm]
* M, N: Dimensions With a 30o angle (max). / A , H : Dimensions including 20 mm of initial pull-out. / For fitting and use instructions, see sheets No800 50 117 and 850 00 001 a.
FOX Hydraulic Oil Tank (Capacity 130 Lit)
FOX Sump Flange
OT.01.130
TT.01
X
60
CHICHEST AXLE MANUFACTURING CO.
61
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX 2.5” Cap
FOX Pedistal
AT.01
TTP.01.01
Al
Al
FOX Deep Gage Cap
FOX Fuel ID Board
D
.01
IDB.01
Al
S
FOX Pedistal
FOX Lever Fastener (Available For Left Side & Right Side)
TTP.01.02
AS.145.00.01
Al
X
62
CHICHEST AXLE MANUFACTURING CO.
63
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX 2” King Pin
FOX Rear Door Hinge
AS.534.00.00
BDH.01
X
X
FOX Pillar Hing
FOX Side Lamp Stand
PH.01
AS.386
G
Material : PA
X D
COLD
FOX Towing Mechanism
FOX Rear Light Cover
TM.01
RLC.01
64
CHICHEST AXLE MANUFACTURING CO.
65
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Wheel Carrier
FOX Front Container Lock
WC.024
FCL.01
X
FOX Slider Winch
FOX Middle Container Lock
DD.01
MCL.01
X
X
FOX Rear Container Lock
FOX Flat Bed Container Lock
RCL.01
BCL.01
X
D
GCOLD
66
CHICHEST AXLE MANUFACTURING CO.
67
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Hinge
FOX Metal Tool Box Lock
TH.01.01
TBL.02
X
FOX Hinge
FOX Plastic Tool Box Lock
TH.02.01
TBL.03
X
Material : PA
FOX Stainless Steel Tool Box Lock
FOX Fire Extinguisher Box
TBL.01
AS.863.00.00
Dimensions (mm)
Code
Weight (kg)
L H D
AS.863.00.00
30x70x30
15
S
68
CHICHEST AXLE MANUFACTURING CO.
69
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
WWW.FOXCH.COM
FOX Tool Box
FOX Tool Box
SIMPLE
Single Floor (L-Type)
Dimensions (mm)
Code
Weight (kg)
L H D
AS.854.00.00
500x450x450
21
Dimensions (mm)
Code
Weight (kg)
AS.856.00.00
400x350x450
17
L H D
AS.855.00.00
1000x450x450
41
AS.852.00.00
1220x500x700
61.5
FOX Tool Box
FOX Tool Box
Drawer
Drawer (L-Type)
Dimensions (mm)
Dimensions (mm)
Code
Weight (kg)
Code
Weight (kg)
L H D
L H D
AS.851.00.00
1000x500x700
61
AS.850.00.00
1220x500x700
73
FOX Tool Box
FOX Valvers Box
Single Floor
For LPG & Fuel Tanker Semi Trailer
Dimensions (mm)
Dimensions (mm)
Code
Weight (kg)
Code
Weight (kg)
L H D
L H D
AS.853.00.00
800x500x700
40
AS.858.00.00
1400x500x700
70
70
CHICHEST AXLE MANUFACTURING CO.
71
03. SEMI TRAILERS PARTS / AIR TANK - MUD GUARD & CLAMP - WATER TANK - HYDRAULIC CYLINDER - TOOL BOXES ...
FOX Tool Box
Single Floor
Dimensions (mm)
Code
Weight (kg)
L H D
AS.862.00.00
2500x500x700
150
FOX Tool Box
Drawer
Dimensions (mm)
Code
Weight (kg)
L H D
AS.864.00.00
2500x500x700
178
72
CHICHEST AXLE MANUFACTURING CO.
04. CURTAIN SIDER PARTS / STAPLE - HOOK - EYELET - CURTAIN BELT CLAMP - & ...
WWW.FOXCH.COM
04
CURTAIN SIDER PARTS
Staple
Hook
Eyelet
Curtain Belt Clamp
& ...
74
CHICHEST AXLE MANUFACTURING CO.
75
04. CURTAIN SIDER PARTS / STAPLE - HOOK - EYELET - CURTAIN BELT CLAMP - & ...
WWW.FOXCH.COM
FOX Staple
FOX Hook
CS.01
CH.02
D
GCOLD
D
GCOLD
FOX Staple
FOX Eyelet
CS.02
CR.01
D
GCOLD
FOX Hook
FOX Curtain Belt Clamp
CH.01
CSC.01
D
GCOLD
S
76
CHICHEST AXLE MANUFACTURING CO.
77
04. CURTAIN SIDER PARTS / STAPLE - HOOK - EYELET - CURTAIN BELT CLAMP - & ...
WWW.FOXCH.COM
FOX Pillar Mechanism
FOX 3 Steps Ladder
PM.02
TSL.01
X
GCOLD
FOX Side Door Lock
FOX Rear Door Holder
SDR.01
DH.01
D
GCOLD
D
FOX Side Door Hinge
FOX Rear Door Locking Set
SDH.01
LM.01
D
D
78
CHICHEST AXLE MANUFACTURING CO.
79
04. CURTAIN SIDER PARTS / STAPLE - HOOK - EYELET - CURTAIN BELT CLAMP - & ...
WWW.FOXCH.COM
Note:
FOX Door Knob Mechanism
AS.823.00.00
X
FOX Belt Tightener
BT.01
S
FOX Chain & Knucle Set (16cm)
SDH.03 (Twin) / DD.608.01.00 (Single)
G
COLD
80
CHICHEST AXLE MANUFACTURING CO.
81
WWW.FOXCH.COM
Note:
Note:
82
CHICHEST AXLE MANUFACTURING CO.
83
8
